Adjust for Vertical Float

LX000444-UN-12AUG94

LX000445-UN-12AUG94

LX1049780-UN-23JUL10

LX245296-UN-15JUL15

A - Vertical Float

B - No-float position

C - Snap Ring

Depending on the position of the steel plates, draft links can be adjusted to allow for vertical float or to lock out float.

IMPORTANT: Make sure that the snap ring (C) has been pulled through the bore of the pin properly, refer to illustration.
